MANTIS
MULTI-SPECTRAL SITUATIONAL AWARENESS PLATFORM
Gyro-Stabilized EO/IR PLATFORM with Advanced
TRACKING (IRST) FOR 24/7 all-weather SURVEILLANCE with INTEGRATED LRF
OBJECT DETECTION & TRACKING
Built-in intelligence enhances object detection and tracking capabilities for improved situational awareness.
MARITIME-GRADE DESIGN
Maritime-grade architecture supports multiple sensor configurations and custom integration for mission-specific surveillance requirements.
MULTI-SPECTRAL IMAGING
Configurable sensor combinations including Daylight, NIR, SWIR (cooled and uncooled), MWIR (cooled) and LWIR (uncooled) imaging engines.
MANTIS - THE ICONIC NAME
Mantis is named after “Mantis Shrimp” for having the most complex eyes in the animal kingdom and the most complex front-end for any visual system ever discovered.
SPECIFICATIONS
(THERMAL CAMERA - MWIR)
| RESOLUTION | 640 x 512p (Lynred Leo MW) | |
| PIXEL PITCH | 15μm | |
| NETD (FOR IR) | <= 25 mK | |
| OPTICAL (LENS) | *20 - 275mm (~14x) (FoV 28° to 1.9°) | |
| OPTICAL FOCUS | Auto/Manual | |
| DRI RANGE (M) | Human: 6KM • Vehicle: 20KM |
(DAYLIGHT CAMERA)
| RESOLUTION | 1080p/720p | |
| PIXEL PITCH | : 1/2.8” | |
| OPTICAL ZOOM (MOTORIZED) | *4.2 - 170mm (40x) (FoV 66° to 1.9°) | |
| OPTICAL FOCUS | Auto/Manual | |
| DRI RANGE (M) | Human: 10KM • Vehicle: 30KM |
(GENERAL)
| Edge AI | Object Detection, Classification and Tracking | |
| VIDEO OUT | RTSP Stream (H.264) Live Video(over Ethernet) | |
| LRF (1535 nM) | Range: (NATO Target) 3KM (+/- 1M) | |
| OPERATING TEMPERATURE | -40°C to +60°C | |
| STANDARD COMPLIANCE | IP 66, JSS 5555, MIL 810G/461 |
(PLATFORM SPECIFICATIONS)
| GYRO STABILIZED | Two Axis | |
| PAN RANGE | 360 Deg | |
| TILT RANGE | -45° to +90° |
